Micro-Computer Real Time Monitoring for Warping Machine (GE518)

Min.Order:

1 Piece

Get Latest Price>

Contact Now Start Order

You can manage your favorites in member center.

Favorites

Basic Info

Product Description

GE518 Micro-computer Real Time Monitoring for Warping Machine

Introduce for Warping Machine

The warping machine is our new developed product. The diameter of the beam can be monitored and the tension can be controlled during warping by micro computer control system, which can make sure the same diameter of the beam group and the length.

This warping machine is suitable for warping cotton yarn, viscose, blending yarn, polyamide and polyester filament, low elastic polyester fiber, viscose, and short-fiber yarn.

Main features for Warping Machine

1. Novel type, simple operation, intelligent identification, auto-reservation of data;

2. Electronic gear, auto-controlled speed track and auto-controlled inspecting machine and power cutting protection system;

3. According to the mother beam, the sub-beam with same perimeter are to be made;

4. The diameter of the beam can be monitored and the tension is stable, which make sure the same diameter of the beams group and the length;

5. The load and unload of the beam is controlled pneumatically, up and down in line, the motion is stable and postion is precise, The break of main shaft adopts pneumatic brakes;

6. The warping machine can set the beams, i. E. According to the mother beam, the sub-beams with same perimeter and rotations can be made.
Micro-Computer Real Time Monitoring for Warping Machine (GE518)

Micro-Computer Real Time Monitoring for Warping Machine (GE518)

Warp line speed	100-1000 m/min
Warp beam size	A:21"×φ42" (inch) B:21"×φ30" (inch) C:21"×φ40" (inch)
Motor power	15 KW AC FC control
Tension roller	Servo motor,AC FC control,adjust the angle of the tension roller in electromotion
Control way	Micro-computer real-time monitoring and showing
Copy precision	the perimeter error of the same group beam is less than 5mm,the tension wave is equal
Max counting range	99999 meters(circles)
