Home > Transportation > Truck > Truck Parts > pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate
pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

0+

US $3.12

0+

US $2.8
Get Latest Price>

Qingdao

60000000 Kilogram/Kilograms per Year

L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal:amily@sdxxhg.com

Contact Now Start Order
You can manage your favorites in member center.
Favorites

Basic Info

  • Place of Origin:
  • Brand Name:
  • Model Number:
  • Material:
  • Thickness:
  • Size:
  • Density:
  • Hardness (Shore D):
  • Tensile strength at break:
  • Notched izod impact strength:
  • Abrasion wear:
  • Melting Temperature:
  • Tensile strength at yield:

Product Description

Product Description

pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate


pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate  has a molecular weight about 10 times higher than pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate is with excellent mechanical properties such as
high abrasion resistance, impact strength and low coefficient of friction.


Details of pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

Material
UHMWPE High Molecular Polyethylene sheet/plate
Place of Origin
 Shandong, China (Mainland)
Molecular Weight
 3-9 million
Method
moulded
Color
black/white/yellow/blue/red/orange or as request
Application
UHMWPE marine fender pad,
UHMWPE guide rail,
UHMWPE suction box cover,
UHMWPE jack pad,ground mats,
UHMWPE liner,
UHMWPE synthetic ice for ice rink.
 Bulk material handling
Food processing and beverage machinery
Mining and mineral processing equipment
Advantages
• Excellent resistance to stress and high resistant to cracking (i.e. it has high tensile and compressive strength)
• High operational temperatures with a melting point of 160°C
• Excellent dielectric properties
• It is highly resistant to most alkalis and acid, organic solvents, degreasing agents and electrolytic attack
• Non-staining




Size of pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate


  Length mm
Width
Thickness
5040
1330
5-260
4730
1230
5-260
3050
1220
5-260
6050
1820
5-260
3030
1550
5-260
4520
2000
5-260
6000
2000
5-260
Any size will be made as request.The length is infinite

Properties of pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

Property
Unit
Value
Density
g/cm3
0.93-0.96
Average molecular weight
g/mol
3million- 10 million
Tensile strength (23°C in air)
MPa
22
Breaking strength
MPa
42
Tensile strain at break
%
600
Charpy impact strength (notched)
mJ/mm2
No break
Ball indentation hardness
N/mm2
42
Shore hardness
--
65-70
Abrasion
%
70-80, steel = 100
Static Friction Coefficient
≤0.16
Kinetic Friction Coefficient
≤0.10
Water Absorption
NIL
Elongation at break at 23°C
%
≥300
Melt Temperature
°C
130-140
Temperature Resistance
°C
-269 to +85

non-toxic uhmw-pe granary liner plate conveyor liner uhmwpe linning


pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate


pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate


pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

pe500 manufacturing uhmwpe sheet non-toxic uhmw-pe granary liner plate

UHMWPE application

UHMWPE marine fender pad/facing pad


UHMWPE guide rail/guide track


UHMWPE Uhle box cover

suction box cover


UHMWPE outrigger pad/jack pad


UHMWPE synthetic ice


UHMWPE rollers


UHMWPE application

Xinxing other UHMWPE products

Xinxing mager in engineering plastic sheets/rods/CNC machined parts.

Other products are UHMWPE/HDPE sheet/board/plate,

UHMWPE marine fender pad,

UHMWPE guide rail,

UHMWPE suction box cover,

UHMWPE jack pad,ground mats,

UHMWPE liner,

UHMWPE synthetic ice for ice rink.

HDPE ice rink barriers/hockey boards

UHMWPE sheets can do CNC machine process


The UHMWPE can do wear blacks,scraper blades,
port crane roller


Related Products

Extruded HDPE sheets

Thickness 3-20mm
Width 100-2500mm
Length 100-6000mm

HDPE Plates thickness 3-25mm

Colors can be made customerized
Packing & Delivery

Shipping

pallets ,wooden case or as request

about 15-30 days

Container

packed into rolls.5-10m/roll

Our Company

Shandong Ningjin Xinxing Chemical Co.,Ltd

Address:Liaohe Street,Dezhou City,Shandong Province,China.
Zip code:253400
Contact Phone Number:86-13181374731    86-18653409198
