UHMW PE forming boards for paper machine

XINXING UHMWPE Uhle box blades and blades are made of UHMW-PE material .
UHMW-PE dewatering element is known for its high dry-film lubricant content.This produces an extremely smooth surface, most importantly resulting in a low friction coefficient a low level of adhesion. No adhesion Excellent chemical resistance

For machines with speeds up to 800 m/min
XINXING dewatering elements in ultra high molecular weight polyethylene set themselves apart by the special sinter press procedure over a long period used to produce them, as well as an extremely high molecular weight plus their extra additive that is specifically tailored to paper machines.All these benefits ensure what is an outstanding service life for plastic coupled with a low coefficient of friction.
Please check the following the work functional picture of UHMWPE Uhle box blades

Application
At machine speeds of up to approx. 800 m/min

XINXING has specialized in UHMWPE Uhle box blades and blades for more than 15 years , we can produce all size and color UHMWPE suction box covers and blades for customer ! Our workers will satisfy your any need .
Any size UHMWPE suction box covers we can supply as long as it within our below standard size :

2000*1000*(10-30)mm;
3000*1500*(10-30)mm;
4700*1200*(10-30)mm;
4500*2000*(10-30)mm;
5000*1300*(10-30)mm;

Why Choose Us

l More than 15 years' professional manufacturing experience with own factory.

l Virgin 100% material produced, high quality with good surface and color make ensured

l GB/T 19001-2008 ; ISO 9001:2008 certification.

l Competitive price, In stock, Fast delivery, and Excellent service.

l OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.

 The properties of UHMW-PE:

Our UHMW-PE sheet Characters:

1.very flat on the surface

2.The thickness tolerance is +2 -0,some made according to your requirements.

3.The color is pure and any color can be made by us.

4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.

5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.

6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.

UHMWPE Advantages & Key Features:

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

--Temperature range: -2600C ~ +800C; Very high resistance to cold,doesn't become fragile even under -1800C

--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications

--Easy Reprocessed

 Packaging : pallet packing or as client need.

XINXING can provide various UHMWPE & HDPE products with the good quality at reasonable price according to your requirement.
