Hot Sale PET Bottle Recycling Line/Plastic Bottle Washing Machine

‍‍

Description:‍‍
With the tremendous development of polyester staple fiber (PSF) technology, recycled PSF production technology has gradually become a general technology. In order to comply with the PSF manufacturer needs, KWELL develop this fiber grade PET bottle washing recycling equipment to match the market demand.
PET flakes produced by fiber grade PET bottle washing line are mainly used for producing 2-D or 3-D PSF, polyester filament yarn, straps, sheet, and film, etc. Every functional section of this PET bottle washing recycling line can be optimized according to the requirements including users' material status, production facilities, product quality, and investment budget, etc. The design proposal is very flexible and customer-oriented.

‍‍
Process flow:‍‍
Bottle bales→Bale Opening→Trommel Filtering→Label Removing→Bottle Pre-washing→Manual Sorting→Wet Crushing→Floating Washing→Drying→Hot Flotation Washer→Drying→Continuous Friction→Continuous Floating Washing→Drying→Label&Dust remover→Flake Optical Sorting→Packing→Clean Flakes


‍‍Main machine function:
1. De-laber
 Bottle bale opening

2.Belt conveyor
 Put the material on the moving belt, which will convey the bottle into label remover

3. Trommel
 Removing rock, stone, dust, loosen caps and small metals, especially, the iron will be removed by high

4.Bottle label separator
 Removing labels from bottles

5.Manual Select working table
 IF the label still in the bottle, worker can remove the label by hand

6.Belt conveyor
Put the material on the moving belt, which will convey the bottle into crusher

7.Crusher
 Crush the material.

8.Screw loader
 Put the flakes into the Hot washer to clean.

9.Floating washer
Cleaning flakes to remove chemicals and separating out rest labels and caps

 10.Hot washer
 Connected with steam boiler. Steam is supplied into washing tank to heat water and flakes. Hot water makes waste; label and glue loosen from bottles.

11.Friction washer
 After crushing material from enters the mouth, through the high speed on the axis of the blade flap and spray water to the common function of good cleaning effect.

12.Centrifugal dryer
 Rejection the water from the flakes, moisture content is less than 2%

13.Pipe drying system
Hot air drying

14.PVC (label) separator
 Used for the PET bottles, round and pressed bottles,effective more than 98%,save energy and labor,without water

15.Storage bunker
Storage materials

Technical parameter:‍‍
Final recycled PET flake quality standard:

Estimated plant parameters:

‍‍

Photos:‍‍

Pacakage:

Photos of factory：

Top Quality:
KWELL is a prestigious plastic recycling machinery manufacturer in China. Our customers have been enjoying a variety of advantages in particular in terms of the dedicated screw designed by our R&D team including good mixing, good dispersion, high productivity, and so on.

Implied Qarranty:
KWELL Machinery guarantees all new products and parts to the first owner-operator to be free from defects in material and workmanship for a period of 12 months from B/L date, under normal use and service.

After-sales service:
1.Send engineers to install, test the machines and offer technology guidance and worker training at customers' factory.

2.Offer 12 months free maintenance and life long service. After the warranty period, spare parts will be provided at basic cost.

3.Build customers database. All machines are traceable.

4.Visit customers and make quality trace periodically and take customers' feedback into account during routine practices.

5.Speed up service and spare parts supply.

Welcome your inquiry for details!

‍
