Yilian brand GSFQ1100-2000 high speed  paper slitter rewinder

This machine is suitable for cutting edge and cutting of large coiled material. Such as printing and packaging plastic membrane type, paper, cloth class and all kinds of paper plastic composite materials such as Lin Mozhi, coated paper, synthetic leather. Max.speed: 300m/min.

Main features:

1 round knife cutting, cutting precision is high, the operation is convenient, and the cutter can be adjusted freely.

2 using A, B axis independent winding, automatic loading and unloading, easy to operate

3 winding with inflatable shaft, automatic tension control, surface friction; center winding, winding product tidy and compact

4 discharge frame adopts hydraulic Wuzhou automatic lifting function

5 waste edge automatic suction discharging device

6 this machine adopts frequency conversion and speed regulation, PLC automatic control, selection of imported photoelectric error correction device, automatic meter, alarm stop, tension digital display and other advanced functions

Main technical parameters:

model GSFQ-1100 GSFQ-1300 GSFQ-1600

diameter of unwinding 1400mm 1400mm 1400mm

width of slitting 1100mm 1300mm 1600mm

diameter of rewinding 1400mm 1400mm 1400mm

min width of rewinding 30mm 30mm 30mm

slitting speed 10-300m/min 10-300m/min 10-300m/min

slitting accuracy ±0.2mm ±0.2mm ±0.2mm

total power 25kw 28kw 35kw

electric 380V/50Hz Tri-phase

requirement of air pressure source 5.5kg/cm2×0.5m3/min

weight 5800kg 6000kg 6500kg

overall dimension 7500×3500×2200mm 7500×3700×2200mm 7500×4000×2200mm
