Brief description

Product applications:
Our products are widely used in the control panels, junction boxes, power distribution box, automation equipment, electronic and power device, welding machine, packing and printing machine.

Product advantages:
1. High efficiency for dust-proof function
2. Free of maintenance
3. Smart size
4. Easy to install
5. High quality sealing gasket, super sealing performance

• 1. Material of net body: ABS resin of flamer resistance
  2. Filter screen material: polyester fiber syntheticresin
  3. Pressure lose of filter screen: initial 6.9mm AQ; terminal 24mmAQ
  4. Max wind speed: 2.0m/sec
  5. Operation temperature range: -10ºC to +55ºC indoors
  6. Effective wind speed: 50m3/min
  7. Collection coefficient: 89%



  Type	Dimension(mm)	Application Fan size（mm）
  SPFA9802	109X109	80X80, 92X92
  SPFA9803	145X145	120X120
  SPFA9804	202X202	120X120, 135X135
  SPFA9805	252X252	150X172
  SPFA9806	320X320	225X225, 280X280
