Name: Lab Electric Seed Blower
Model: CFY-II


Detailed Product Description
PASS ISO 9001

Brief Description:
This equipment sorts up the samples according to theory of the float speed of corpuscle in the air. It is suitable for both light seed (vegetable seed, flower seed) and heavy big seed (like rice, corn). It also can get an ideal neatness for some grass seed, like bluegrass, cogongrass, etc.

Working principle:
Classify samples according to aerodynamic behavior (floating speed) of particulates in air stream

Characteristics:
1. Metal shell, strong vibration resistance
2. Beautiful shape, small noise, reliable operation, good safety.
3. Wind speed is adjustable according to granule size
4. Can achieve the best effect, and can be timed.

Operation Procedure:
1. Install the equipment as picture 1.
2. Switch on.
3. Put the seed or grain in the material cup, then push in, press down the button, the indicator light turns on, dextrorotary the wind-force adjust button, (turn right-wind force becomes heavy, turn left-wind force becomes light), choose the suitable wind-force to test. Max fixed time is 10 minutes. It can set up the time during 0-10 minutes. After fixed time, if need to restart the equipment, must switch off the power, then start, make sure the fixed time on"0".

Technical parameters:
