Name: Plant Photosynthesis Analyzer
Model: 3051C
1. Introduction
This meter is connecting laptop calculating with gas analysis to measure and calculate the indexes of photosynthesis, respiration and transpiration.
2. Characteristics
1). Use laptop to connect with CO2 Meter and leaf chamber, receiving the data from sensors.
2). Can test photosynthetic rate, steaming rate, stomatal conductance, and CO2 density of plants.
3). Software will show the data by curves, easy to operate,
4) Both AC and DC available,
5). Light weight, small volume, portable.
3.Components:
Main controller, handle, leaf chamber, gas tank
4.Technical parameters
| Testing parameter | resolution | Measure range | accuracy |
| CO2 | 1ppm | 0-1000ppm | ±1% |
| Relative humidity | 0.1% | 0-100% | 2% |
| Temperature | 0.1°C | 0-50°C | 0.2°C |
| Illumination | 1 uE | 0-3000 uE | ±10 uE |
