Detailed Product Description

Name: Portable Microclimate Information Meter
Model: NL-5/NL-5H
PASS ISO9001


Introduce:
Microclimate information collector (system) can acquire air temperature, humidity, illumination, Wind direction and speed, rainfall, etc. Widely used in facilities agriculture, forestry, horticulture, animal husbandry, and other fields, and fulfill to carry out conduct of automatically monitor, automatic control and intelligent management to the facilities for comprehensive agricultural ecological information.

Characteristic:
1.   Big  LCD screen, film-style keypad, can display real-time sampling date and time (year, month, date, minute and second), groups, temperature, humidity, illumination, Wind direction and speed, rainfall and other parameters, Apparatus compact beautiful and very convenient . (can accord to the users requirements to increase and change measuring parameters, such as: PAR radiation, wind direction and speed, rainfall, soil water potential, soil PH, EC soil conductivity, GPS positioning function, etc.).
2. User settings himself, can be demanded the closure of the parameters do not need access.
3.  Automatically collect various kinds of parameters datum, datum can be passed through the interface software (for free) to download to your computer.
4.Be able to shown the all the parameters of the visual data measured in the form of chart and curve to the user.
5.  Strongly expanded: procedures modular system structure and function to facilitate expansion or shielding.

Standard Sensors equipped are:
1.  Temperature and Humidity;
2. Illuminaiton;
3.  Rainfall;
4.  Wind speed and Direction;
Other sensors as below sheet needed can be customized.
Sensor list for selection:


Technical Parameters of the controller:
Solar power supply: 10WP
Standby power: DC-9V/ 1A
Watt: ≤ 1.5W
Capacity: 1M (local storage) + 4G (SD CARD)
Waterproof rate: IP54

Technical parameters of sensors (OPTIONAL):
