> Instruments & Meters > Test Instrument > Test Machine > Dsx Series Laboratorial Sieve Shaker or Vibrating Screen
Detailed Product Description
Table model structure
It's widely used in the grain, the fuel oils screening test.
Name: Electric Vibrating Screen
Model: DSX
Characteristic:
Electrically screening instrument uses the table model structure, the body sieves by three planes struts, makes the plane rotation through the eccentric link motion gear the automatic device to sieve, has the structure compact reasonable, the revolution steady, the performance is stable, merit and so on ease of operation, widely adapts the grain, the fuel oils screening test.
Technical parameter:
| Max sieving quantity range | 500g |
| Sieving frame level | 3 layers |
| Sieving range | 100mm |
| Rotation speed | 115± 5r/min |
| Sieve diamete | 220mm |
| Power | 60W AC220V 50Hz |
| Weight | 13kg |
| Packge Size | 42*45*31CM |
| Power resources | 60W |
| Along reversal time | 60S/60S |
