Toilet paper rewinding machine Description

This machine adopts international new PLC computer programming technology (system can be upgraded), frequency control, automatic electronic brake. The touch-type human-machine interface operating system uses a coreless rewind forming system. application the PLC program wind column forming technology achieves the characteristics of faster rewinding and more beautiful molding.

Working Principle of Toilet paper rewinding machine

Automatic feeding→synchronous conveying→embossing→punching→automatic winding→cutting→packing→sealing.

1. Rewinding---The main purpose of the toilet paper rewinding machine is to process the large shaft paper into a long strip of toilet paper roll.

2. Cut the paper---The long piece of toilet paper cut by the paper cutter is cut into semi-finished products of the length required by the customer.

3. Packaging---Packaging can be packaged in a packaging machine or manually wrapped, and the semi-finished products of the toilet paper are packaged and sealed by a sealing machine.

Toilet paper rewinding machine Main Features:

1, PLC used in automatic rewinding, automatic delivery of finished products, immediately reset rewinding, automatic trimming, spray glue, sealing synchronization once completed. Instead of the traditional waterline trimming, to achieve a new trimming sticky tail technology, finished products left 10mm-20mm tail, easy to use. To achieve a loss of paper tail, thereby reducing costs.

2, PLC used in the finished product in the rewinding process before the first loose, to solve the finished product for a long time storage, loose core phenomenon.

3, the application of the original paper monitoring system, broken paper automatically shut down. In the high-speed operation of the process, real-time monitoring of the base paper to reduce the loss caused by broken paper to ensure the normal operation of high-speed equipment.

About us:

Gongyi Shaolin Machine Manufactory was founded in 1995, we specialized in toilet paper making machine,toilet paper rewinding machine, paper napkin making machine, facial tissue folding machine, egg tray making machine, paper tube machine,pulp making machines and so on.

According to different requirements of raw materials, capacity and finished products, our factory can provide you with complete design, installation, commissioning and other services, help you get the most profit from a smaller investment.

We stick to the principle of "customer first, quality first", after more than 20 years of continuous development, our products not only popular in China, but also being exported to North America, Europe, Oceania, Middle East Asia, Southeast Asia, South Asia and other regions.

Gongyi Shaolin Machine Manufactory looks forward to your attention and patronage! In the rapid competitive market, We sincerely hope to shakes hand with you to create a bright future! Because your success speak our success!

Welcome to contact us!
