Product name：High tensile hex head bolt Din931,933
Item：WBF001
Details：
Material:carbon steel,alloy steel, stainless steel.
Diameter : M12-- M36(1/2"-1 1/2")
Length:25mm --1000mm
Property class as per ISO 898:8.8-10.9,GB 1231:8.8S,10.9S,JIS 1186;EN 14399;ASTM A325/A325M,A490/A490M.
For tension control structural series product capacity diameter from M12 to M36(1/2"-1 1/2") Length from 25mm to 1000mm, property class as per GB3632:10.9S;ASTMF1852 JSSII-09
| Size | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 |
| Pitch of Thread | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | 2.5 | 2.5 | 3 |
| Width across flat,max | 7 | 8 | 10 | 13 | 17 | 19 | 22 | 24 | 27 | 30 | 32 | 36 |
| Thickness of head | 2.8 | 3.5 | 4 | 5.3 | 6.4 | 7.5 | 8.8 | 10 | 11.5 | 12.5 | 14 | 15 |
| DIN931 1≤125 | 18 | 22 | 26 | 30 | 34 | 38 | 46 | 50 | 54 | |||
| GB5782 1≤125 | ||||||||||||
| L of thread 125<1≤200 | 24 | 28 | 32 | 36 | 40 | 44 | 52 | 56 | 60 |
