Size range: 15~2000mm, ½~84in.

Pressure range: 1-10MPa, 1:2 safety factor, which means bursting pressure is 2 times higher than the operating pressure.

DN15~200 (carbon steel, ductile iron, aluminum alloy, stainless steel-casting process)；DN250~2000 (45#steel, stainless steel welding technology ).

Material of valve sleeve: NR, EPDM, CR(chloroprene rubber), NBR, butyl rubber, FPM, Hypalon rubber.

friendly and cost effective frame pinch valves that do not compromise on good quality. We ensure that our pinch valves are manufactured to suit various applications.

valve sizes are available from 50mm to 350mm. Larger sizes are available on request.

Pinch valves all over the world operate on the same principal and are manufactured with heavy material, therefore making them cumbersome to handle.

Frame Pinch Valves are Built with Cost-Saving in Mind

Frame pinch valves differ from the norm in the sense that they are built from lightweight materials, however, the design takes care of the body strength, and the same principal applies for the wear sleeve.

Lighter built valves require less installation effort in difficult applications, less bracketing on piping, and less transport costs.
